Drawn wire pin technology is a total process solution that offers a large variety of pin sizes, types and features, ina a range of shapes, along with a continuous packaging format compatibility with high speed automation. This flexibility along with high-speed automation provides the lowest applied cost for any interconnect pins available on the market, making them ideal for high-volume printed circuit boards requiring reliable connections and high-performance connectors.
VIEW PRODUCT LINE
The drawn wire pin technology allows you to design a component to your exact specifications without costly engineering charges. Along with specialized component capability, all PCB pins are also designed with automation in mind. Autosplice's automation technology is compatible with both through-hole and surface mount (SMT) process technologies. The Autosplice end-to-end PCB pins offer a single turnkey process solution to mixed technology manufacturing for custom contact pins and connectors by combining component design and automated insertion into a streamlined process.
Component Features
All drawn wire PCB pin products are supplied on continuous reel, notched at each end to your exact length specification. The notch creates a tapered lead-in, eliminating the potential for board damage during assembly and helping guide each pin into position. Additionally, end-to-end pins can be supplied with a variety of features designed to maximize component to board retention for both soldered or solderless connections in standard or custom pin diameter specifications.
Continuous Reel Pin Packaging
Packaged end-to-end on continuous reel, PCB pin components are ready for machine assembly at various levels of automation. The same component reel supplies pins to Semi-Automatic, Stand-Alone or In-Line Insertion systems. Additionally, the modular insertion tooling for all systems are interchangeable for future machine upgrades.
FEATURES
- Continuous reeled, end-to-end packaging for automatic machine assembly
- Wide range of user defined specifications
- Thousands of configurations tooled
- Pins available for SMT and through-hole application
- Soldered and solderless pin types available
BENEFITS
- Allows highly reliable, cost saving automation
- Maximizes design flexibility
- Meet special design requirements without incurring NRE costs
- Design for manufacturability
- SMT and mixed technology process compatibility
- Optimize manufacturing processes for lower costs while ensuring reliable connections across various printed circuit boards
